Mindman VLG Series: Vacuum Pick-Up Unit (Single Row / Suction Cup Array) - VLG200S-P1L-40BN-161

Description

Vacuum Pick-Up Unit (Single Row / Suction Cup Array),Length:200mm,Number of Rows:1 Row,Suction Cup Diameter:ø40mm,Suction Cup Material:NBR (Nitrile Rubber),Vacuum Generator:161

Features

  • Suitable for robot arms handling large workpieces by suction
  • Three suction face types: sponge (ring type and full sponge) and suction cup array
  • Built-in high-flow vacuum generator with a maximum suction flow of 760 l/min (rated value for the specification with 3 built-in ejectors). A vacuum pump compatible version is also available.
  • Once the robot arm flange mounting plate is fixed to the arm, the unit simply slides into place for easy installation, improving operability and safety.
Product form

Vacuum Pick-Up Unit (Single Row / Suction Cup Array),Length:200mm,Number of Rows:1 Row,Suction Cup Diameter:ø40mm,Suction Cup Material:NBR (Nitrile Rubber),Vacuum Generator:161Features Suitable... Read more

SKU: VLG200S-P1L-40BN-161

$205.00 Excl. VAT

    • Image may not be representative of actual product.

    Description

    Vacuum Pick-Up Unit (Single Row / Suction Cup Array),Length:200mm,Number of Rows:1 Row,Suction Cup Diameter:ø40mm,Suction Cup Material:NBR (Nitrile Rubber),Vacuum Generator:161

    Features

    • Suitable for robot arms handling large workpieces by suction
    • Three suction face types: sponge (ring type and full sponge) and suction cup array
    • Built-in high-flow vacuum generator with a maximum suction flow of 760 l/min (rated value for the specification with 3 built-in ejectors). A vacuum pump compatible version is also available.
    • Once the robot arm flange mounting plate is fixed to the arm, the unit simply slides into place for easy installation, improving operability and safety.
