Mindman RDC Series: Sensor Mounting Bracket - DT7-2

Description

Sensor Mounting Bracket,Applicable Model:MCQN/MCQV3/MCBQV3/MCQV3L Tie-Rod Cylinders,Tie Rod Diameter:ø8.9

Features

  • Wiring: 2-wire, 3-wire
  • Switching logic: normally open
  • Contact type: solid-state, solid-state NPN, solid-state PNP
  • Operating voltage range: 5~30V DC
  • Maximum switching current: 50~80mA max.
  • Contact capacity: 1.5~2.4W max. (*1)
  • Current consumption: 2mA @24V DC max. (*5)
  • Internal voltage drop: 4.0V@50mA max, 1.2V@80mA max. (*5)
  • Sensing magnetic field strength: 40~1000 gauss (*5,6)
Product form

Sensor Mounting Bracket,Applicable Model:MCQN/MCQV3/MCBQV3/MCQV3L Tie-Rod Cylinders,Tie Rod Diameter:ø8.9Features Wiring: 2-wire, 3-wire Switching logic: normally open Contact type: solid-state, solid-state NPN,... Read more

SKU: DT7-2

$46.50 Excl. VAT

    • Image may not be representative of actual product.

    Description

    Sensor Mounting Bracket,Applicable Model:MCQN/MCQV3/MCBQV3/MCQV3L Tie-Rod Cylinders,Tie Rod Diameter:ø8.9

    Features

    • Wiring: 2-wire, 3-wire
    • Switching logic: normally open
    • Contact type: solid-state, solid-state NPN, solid-state PNP
    • Operating voltage range: 5~30V DC
    • Maximum switching current: 50~80mA max.
    • Contact capacity: 1.5~2.4W max. (*1)
    • Current consumption: 2mA @24V DC max. (*5)
    • Internal voltage drop: 4.0V@50mA max, 1.2V@80mA max. (*5)
    • Sensing magnetic field strength: 40~1000 gauss (*5,6)
