Mindman MCGI* Series: Compact Twin Guide Rod Cylinder (Lift Type / Slide Bearing) - MCGI-12-20-50

Description

Compact Twin Guide Rod Cylinder (Lift Type / Slide Bearing),Application:Lift Type,Bearing Type:Slide Bearing,Cylinder Bore:20mm,Stroke:50mm,Port Size:M5×0.8

Features

  • Air pressure drives the piston rod to pull and push, and the twin guide rods give precise operation.
  • Mounting grooves are formed around the outside of the cylinder body during extrusion, making sensor mounting and position adjustment extremely simple.
  • Compact mounting design: the RCI sensor sits flush on the body without protruding or taking up space.
  • The entire series is magnet-equipped.
Product form

Compact Twin Guide Rod Cylinder (Lift Type / Slide Bearing),Application:Lift Type,Bearing Type:Slide Bearing,Cylinder Bore:20mm,Stroke:50mm,Port Size:M5×0.8Features Air pressure drives the piston... Read more

SKU: MCGI-12-20-50

$175.00 Excl. VAT

    • Image may not be representative of actual product.

    Description

    Compact Twin Guide Rod Cylinder (Lift Type / Slide Bearing),Application:Lift Type,Bearing Type:Slide Bearing,Cylinder Bore:20mm,Stroke:50mm,Port Size:M5×0.8

    Features

    • Air pressure drives the piston rod to pull and push, and the twin guide rods give precise operation.
    • Mounting grooves are formed around the outside of the cylinder body during extrusion, making sensor mounting and position adjustment extremely simple.
    • Compact mounting design: the RCI sensor sits flush on the body without protruding or taking up space.
    • The entire series is magnet-equipped.
